The Delta Icon Pro controller is a multi-screen graphics video wall controller running on the Windows® platform. The Icon Pro controller drives multiple video wall cubes to form one large logical screen called a video wall or a data wall. It is designed for capturing, displaying and managing varied sources on the video wall. Icon Pro controller is a configurable system and can drive multiple video walls having up to 100 units or more. It is flexible enough to display local applications, network-streamed desktops, and direct-connected DVI, RGB and video inputs – anywhere, and at any size on the large system display, all within your 24×7 control room. Icon Pro offers the information you need to see, in the way you wish to see it and where you wish to see.
Features
Operating Systems
Runs on all standard Windows® operating systems, support 32 bit/64 bit system. It also offers support for Linux® emulation to ensure easy integration with Unix/Linux workstations.
Processors
Icon Pro series controller can support a variety of Intel processors such as Dual core, Quard Core Xeon, i3 and i7 processors to deliver the optimal performance for displaying high-end visualization applications.
In-built Redundancy
Icon Pro series is designed for continuous 24×7 operation, specifically for mission-critical visualization environments, where availability of detailed information to make effective decision is the key. Icon Pro has in-built redundancy a critical component for uninterrupted operation.
- Redundant Hot-swap Power Supplies
- Redundant Hot-swap HDD
- Redundant Ethernet
- Redundant Fans
- Redundant Controller
Advanced Processing Architecture
Icon pro controller supports PCI- express, switch fabric and intelligent high-bandwidth backplane architecture, creating a true non-blocking communication infrastructure for high demanding applications. This architecture provides a significant increase of PCI bandwidth which is best realized when multiple RGB input sources are included in the system configuration.
Input/Output Resolution Capability
Icon Pro is able to capture and display a wide range of visual sources (i.e. SD video/HD video/DVI/RGB/Component/HD-SDI/IP streams) with resolution support up to 4K and drives all types of digital and analog display devices with a native resolution up to WUXGA.
Powerful Universal Inputs
Icon Pro series controller can be configured to specific direct input connection requirements. It supports single/dual link DVI signal, analog RGB and component video inputs and display input signals at full frame rate – no dropped frames regardless of output window size – while maintaining perfect visualization. Each source can be positioned anywhere on the wall, up to any size.
Streaming Video Inputs
Icon Pro controller supports decoding of multiple camera types, multiple formats (MPEG-2, MPEG-4, H.264), custom formats and resolutions from QCIF, D1 to megapixel. Decoding and display of video streams using RTP, RTSP, TCP, UDP, and IP network protocols, including Unicast and Multicast protocol is possible. Hundreds of IP video streams can be decoded and displayed across any large video wall.
Diagnostic and Remote Monitoring Options
Icon Pro series controller can monitor the health of the complete system, including power supply, CPU, fan, temperature and chassis intrusion detection, etc. System can generate a LAN alert-SNMP trap in case of critical component failure (i.e., power supply failure) and record in a log file for future reference. System monitoring is possible locally as well as from a remote location.
Specifications
| ICON pro controller | ||
| Chassis | 19” industrial Rack mount Lockable front door to protect drives |
|
| Operating System Platform | Window 7 / 10 – 64 bit, Windows 10 LTSB, LTSC IoT Ver. , Win Server 2016/2019 | |
| Processor options | Intel Xeon, Intel i3/ i5/ i7/i9 Series | |
| RAM | Std. 4 GB DDR3, higher on request | |
| HDD | Support up to minimum 6 HDD SSD.: 500 GB , can be upgraded on request |
|
| Networking | Dual-port Gigabit Ethernet Controller inbuilt | |
| Supports Add on copper/ optical fiber adapters | ||
| RAID | RAID 0, 1, 5, 10 support | |
| Cooling | Forced cooling | |
| Indicators | LED’s for HDD activity and Power status | |
| Input / Outport support | 8 USB/ LAN/ VGA/6 SERIAL SATA/IDE port | |
| Switches | Power On/Off and System Reset | |
| Monitoring options | CPU, FAN, Temperature, chassis Intrusion detection and alarms | |
| Accessories | DVD +RW ,Keyboard and mouse | Outputs | 2 or higher |
| Output Resolution support | DVI: 1920×1200 RGB: 2048×1536. DP:3840×2160 | |
| Universal Inputs Formats | DVI /RGB/Component/HDMI/DP | |
| Streaming Input | Hardware & Software Decoding of streaming media input | |
| Resolution Support for IP streams | 4K, HD, D1, VGA, CIF & QCIF | |
| Format | MJPEG, MPEG-2 , MPEG-4, H.264, Custom formats | |
| Audio | High Definition Audio CODEC | |
| Supported Input Type | 4K/ SD video / HD video / DVI/HDMI/ RGBHV / VGA / Component video / HD-SDI / Streaming video / Network / RSS feed / Ticker |
|
| Redundancy support | Power Supply, HDD, Cooling Fan, LAN port & Controller | |
| Scalability | Display multiple source windows in any size, any¬where on the wall |
|
| Control functions | Brightness / contrast / saturation / Hue / Filtering/ Crop / rotate | |
| Power Supply | (1 + 1) Redundant AC-DC high-efficiency power supply w/ PFC AC Voltage 100 – 240V, 50-60Hz |
|
| Temperature | Operating Temperature: 0° to 40°C (32° to 95°F) Non-operating Temperature: -40° to 70°C (-40° to 158°F) |
|
| Humidity | Humidity: 10 – 90% non-condensing | |
| Wall Management Software- ICON PRO Studio | ||
| Display & Scaling | Display multiple sources anywhere on the display up to any size | |
| Input Management | All input sources can be displayed on the video wall in freely resizable and movable windows |
|
| Scenarios management | Save and Load desktop layouts from Local or remote machines | |
| Layout Management | Support all Layout from Video, RGB, DVI, Internet Explorer, Desktop and Remote Desktop Application | |
| Set any layout as Default layout to launch at Application Switch ON | ||
| SNTP support | Yes | |
| Authorization | Four levels ( Admin, Supervisor, User, Guest,) | |
| Control | Remote Control over LAN | |
| Window Title | Add window title as per user convenience | |
| Region Management | Allocate regions to specified users | |
| Layout Launch | Auto launch of Layouts according to user specified time /event | |
| Logs | Yes ( CSV file format) | |
| Ticker Control | Yes | |
| Hot Keys | Yes | |
| Alarm management | Yes | |
| Multi View Option | Multiple view of portions or regions of Desktop, Multiple Application Can view from single desktop |
|
| Remote management | simultaneously Control over user workstations | |
| Multiple concurrent client | Yes | |
| KVM support | Yes | |
| Console View | Primary Display, Secondary Display, Full Desktop, Selected application or region |
|
| CUBE Management Software ( ICON Pro- Cube Control) | ||
| Cube Health Monitoring | Yes | |
| Pop-Up Alert Service | Yes | |
| Logs | Yes | |
| Email Notification | Yes | |
| Graphical User Interface | User Friendly | |
| Control | Control l the entire wall or a selected cubes from anywhere (local or Remote location) over LAN |
|
